Garments that can measure a wearer's body temperature or trace their heart activity are just entering the market, but the European project BIOTEX weaves new functions into smart textiles. Miniaturised biosensors in a textile patch can now analyse body fluids, even a tiny drop of sweat, and provide a much better assessment of someone's health.
It is 7 o’clock in the morning. You check yourself in the mirror, adjust your collar, and consider the hectic day ahead. But at least you know that the stress won't damage your health, for this is no ordinary set of clothes you are wearing. Embedded within the fabric are numerous sensors, constantly monitoring your vital signs. If danger signs are detected, the garment is programmed to contact your doctor – and send a text message telling you to take it easy.
measurements, body temperature or electro-cardiograms. But no-one has yet developed biochemical sensing techniques that can take measurements from fluids like sweat and blood. We are developing a suite of sensors that can be integrated into a textile patch. The patch is a sensing and processing unit, adaptable to target different body fluids and biochemical species. At the very least, some basic biochemical analyses could complement the physiological measurements that can already be monitored. In some circumstances, fluidic analysis may be the only way to get information on a patient's health status.”

Sensing success
But there is a simple reason why researchers have shied away from developing smart textiles for fluid monitoring: it is extremely tricky. How do you collect a fluid and transport it to a biosensing unit? Can you perform non-invasive blood tests? Can measurements be reliable and accurate with tiny volumes of liquid? The BIOTEX partners – universities and small enterprises from Italy, France and Ireland – have collaborated with CSEM to overcome some of the technical barriers to biosensing textiles.
One of the main achievements of the project has been the development of a suite of prototype ionic biosensors, capable of measuring sodium, potassium and chloride in sweat samples. Another probe measures the conductivity of sweat and a miniaturised pH sensor uses colour changes to indicate the pH of sweat. An immunosensor, which could be integrated into wound dressings or bandages, can detect the presence of specific proteins in fluid samples.
Several of the BIOTEX probes, including the pH sensor, use colour changes or other optical measurements. For example, as sweat passes through the pH sensor it causes an indicator to change colour which is detected by a portable spectrometer device. The immunosensor technology works in a similar fashion. Plastic optical fibres (POFs) are woven into the fabric so that light can be supplied to the optical sensors and the reflected light directed to the spectrometer.
Small and smart
The BIOTEX oxygen probe measures levels of oxygen saturation in the blood around the thorax using a technique called reflective oximetry. A cluster of POFs allows a large surface of the thorax to be illuminated and improves the collection of the reflected red and infrared light used for the oximeter sensor. Signal processing also improves the sensitivity of this method. “The volume of fluid secreted from sweat glands is just a few millilitres over a small surface,” says Luprano, “and the body's heat means this is rapidly vaporised. We needed some kind of pump that could collect sweat in one area and bring it to the sensor array, where it could be channelled through each sensor.” The solution uses a combination of hydrophilic (water-loving) and hydrophobic (water-repellent) yarns. It is possible to weave these two threads to direct the sweat through fabric channels to the sensor array. It is a passive system using no power, thereby reducing the power demands of the BIOTEX system (and the weight of a battery pack that the wearer would have to carry). In the first BIOTEX trials, the smart patches will be worn in clothes by people with obesity and diabetes, as well as athletes. Once the technology has been validated, the plan is to take on industrial backers to commercialise it. Meanwhile, a large EU-funded project within the same SFIT group, called PROETEX, is integrating the technology with other micro- and nanosystems for specific applications (fire fighting and rescue teams). However, whilst BIOTEX has solved several of the technical aspects of continuous biochemical monitoring, Luprano calls for more research into the application of this technology. “It's new and healthcare providers are not used to it. We are not used to the information that continuous, remote monitoring can provide – so different to the one-off laboratory tests that are usually taken. BIOTEX makes this remote monitoring possible, but more research into the links between these indicators and disease conditions and states will make it realistic. Nevertheless, in the long-term we expect continuous monitoring, made possible with smart textiles, to make a major improvement to the way we approach the treatment of metabolic disorders and leisure.”
